Optical Alignment Infrared EMMC Reballing Machine OEM BGA Soldering Equipment

Large Image : Optical Alignment Infrared EMMC Reballing Machine OEM BGA Soldering Equipment

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	WDS
Model Number:	WDS-620

Payment & Shipping Terms:

Price:	$3,980.00/Sets
Packaging Details:	Wooden package

Contact Now

Optical Alignment Infrared EMMC Reballing Machine OEM BGA Soldering Equipment

Description

Warranty:	3 Years	Voltage:	220V/50HZ, 110V-240V
Current:	Dependable	Customized Support:	OEM
Type:	Digital	Temperature Control Accuracy:	±2℃
Tip Type:	HOT Air Nozzle	Condition:	New
Applicable Industries:	Manufacturing Plant	Function:	Repair Motherboards
After-sales Service Provided:	Video Technical Support	Total Power:	5300W Max
BGA Chip Size:	Max.7070mm / Min 11Mm	Heater Power:	Upper Temp.one 1200w,second Temp.zone1200w,IR Temp.zone 2700w
Product Name:	Chip Soldering And Desoldering Machine	Electrical Material:	Driving Motor+PLC Smart Temp.controller+ HD Camera
PCB Size:	Max410380mm Min1010mm
High Light:	Infrared EMMC reballing machine , OEM BGA soldering equipment , EMMC infrared reballing station

Product Description

Our BGA Rework Station/ BGA reballing station are widely used to replace and repair the BGA chip in laptop, mobile phone,xbox360,ps3,etc.
The main user is repairing shops and factory to provide the after-sales service and rework.WDS-620 infrared heating SMD Soldering Station phone repair machine with optical alignment system

Main Features

BGA Rework Station
Model:WDS-620
♦ Automatic&Manual operation system
♦ 5 million CCD camera optical alignment system mount precision ±0.01mm
♦ MCGS touch screen control
♦ Laser position
♦ Repair success rate 99.99%

Independent 3 heating zones temperature control system

1.The upper and lower hot air heating,which can heat up at the same time from the top of the component to the bottom of the PCB; bottom IR heating, temperature precision control within ±1℃.8 segment temperature control independently.

2.Hot air district heating for BGA and PCB at the same time,and large area IR heater preheating up for the bottom of PCB to avoid completely PCB deformation during reworking,the upper or lower temperature zones could be used alone and combine freely the energy of up and lower heating element.

3.Adopted high precision K-type thermocouple close-loop control and PID parameter self-setting system;4 temperature curves can be displayed with instant curve analysis function and multi-group user data can be saved;temperature can be tested precisely through external measurement interface,curves can be analysed,set and correct on the touch screen at any time.

Precision optical alignment system

Using high definition and adjustable CCD color optical alignment system,beam split,amplification ,lessening,fine adjustment and auto focus with the function that automatic color aberration resolution and brightness adjustment,adjustable image contrast;equipped with 15 ” high definition LCD monitor.

Multi-functional and humanized operation system

1.Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many kinds of titanium alloy BGA tuyere can be rotated in 360 degree for easy installation and replacement.
2.X,Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm.WDS-620 infrared heating SMD Soldering Station phone repair machine with optical alignment system

Superior safety protection function

With the alarm function, after the BGA welding, the machine can alarm by itself.In the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.Temperature parameter has password protection to prevent any modification.

How to separate BGA chip from motherboard?
How to replace a new BGA chip?

Repair steps:
1) Separate the BGA chip from motherboard –we called desoldering
2) Clean Pad
3) Reballing or replace a new BGA chip directly
4) Alignment/Positioning – Depend on experience ,silk frame ,optical camera
5) replace a new BGA chip - we called Soldering

Product Paramenters

Power supply	AC 220V±10％ 50/60Hz
Total power	Max 5300W
Heater power	Upper temp.zone 1200W,second temp.zone 1200W,IR temp.zone 2700W
Electrical material	Driving motor+PLC smart temp.controller+HD camera
Temperature controlling	(high precision K-sensor)(Closed Loop),independent temp.controller,the precision can reach ±2℃
Locating way	V shape slot,PCB support jigs can adjust,laser light do fast centering and position
PCB size	Max 410×380mm Min10×10mm
Applicable chips	Max 70×70mm Min1×1mm
Overall dimension	L650×W630×H850mm
Temperature Interface	1 pcs
Weight of machine	60KG
Color	White&blue
Work mode	5 modes for choose,auto/manual work mode can be changed freely

Detailed Images

Packing&Shipping

1, Standard Export Wooden cases
2, Delivery in 2 workdays after payment confirm;
3, Shipping by TNT,DHL,FEDEX , or by air or by sea
4, Loading port: Shenzhen or Hongkong.

Company Introduction

Shenzhen Wisdomshow Technology Co., LTD.
** Professional BGA Rework Station Manufacturer **

1. Following the business philosophy of "professional, integrity, excellence, customer first";
2. One of the leading manufacturers of BGA rework stations;
3. Over 10 years' experience in the BGA rework industry;
4. All models have passed the CE Certificate and ISO;
5. 100% QC inspection before shipment;
6. Customized brand logo is acceptable;
7. Owning a large market share in the world;

Our Services & Advantages

1. 24 hours technical support by email or calling;
2. Warranty:one year free,but all the other relative cost should be on the buyer's account;
3. Technology Support : Provide Demo operation video for training ;If you have time,welcome to our company,we will arrange engineers to show you the operation;
4.Friendly English User manual provided; Good and professional after-sales service;
5. Give great discount to AGENCY to ensure agents profit.

Buyer Feedback

Our Customers' Voice:
1.Hi mate, your best price and high purity product is so competitive in my country , this let me make much profit , my customers are really like it . cooperate with you is so wonderful ! thank you ! ---------Richard---Turkey

2.i have received my products , your packing is do discreet and perfect , it really amazed me .i will order more from you as soon as possible. thanks a lot. -----------Robet--Australia

3.i have cooperated with you for many times , your product quality is so great , that is why i still buy the products from you
.thank you . ------------- Corentin ---Brazil

Order Now

If any questions please send INQUIRY or CHAT with us ,
We will be glad to service you !
Now you can order freely!!!
