Product Details:
|
| Tube Voltage:: | 40-130kV (Adjustable) | Tube Type: | Sealed |
|---|---|---|---|
| Focus Spot Size: | 3μm | Detector: | Flat Panel Detector (FPD) |
| Packing Weight: | 1950 Kg | Radiation Safety Standard: | < 1uSv/hr.（International Standard） |
| High Light: | 100kv SMT X Ray Machine,FPD SMT X Ray Machine,Drill Bit X Ray Scanner Machine |
||
S9200 100kv X Ray Scanner Machine 5μM For Diamond Core Drill Bit
| Item | S-9200 | |
| Panel Detector | Pixel Pitch | 49.5um |
| Inspection area | 600mmx600mm | |
| Detector Tile Angle | 70 Degree | |
|
X-Ray Source Tube |
Optical Tube Style | Closed tube |
| Optical Tube voltage | 130KV | |
| Optical Tube current | 250UA | |
| Optical Tube focus size | 5um | |
| Optical Tube Power | 40W | |
| System Magnification | 1200X | |
| Geometric Magnification | 125X | |
| Sample Table | Diameter | Φ520mm |
| R axis (horizontal rotation) | 360° | |
| Tube axis moving up and down | 380mm | |
| Detector moving up and down | 380mm | |
| Platform Deadweight | 10KG | |
| Software Function | Size Detection | Point to point&Line to line angle measure |
| Bubble Detection | casting solder joint bubble can be measured and inspected for cracks | |
| Power | Power supply | AC110-230VAC, 50/60Hz |
|
Computer |
Brand | Dell |
| Operation System | Windows10 | |
| Display | 24”LCD | |
| CPU | Intel i5 6500 | |
| Radiation Safety Standard | < 1uSv/hr(International standard) | Radiation leakage dose＜1µSv/h(GB15208.1～2005) |
|
X-Ray Dimensions |
Dimension | 1500mmX1300mmX1800mm |
| Weight | 1500KG | |
|
Warranty
|
Tow years | Two years warranty |
SMT, BGA, CSP, Flip Chip, LED Detection, Semiconductor, Packaging components, Battery Industry, Electronic components, Automotive parts, Photo-voltaic, Aluminium Die-casting, Moulding Plastic. Ceramics, other special industries.
Standard configuration
| Items | Number | Unit | Specification |
| Closed X-ray tube | 1 | piece | 130KV |
| Sample Table | 1 | piece | 900mm*700mm |
| Inspection Area | 1 | piece | 900*700mm |
1. Adjust the speed of the stage through the space bar: slow, normal, fast
2. Keyboard control X, Y, Z1 Z2 the four-axis movement.
3. The user can control the speed of the stage by programming
Fully automatic BGA detection program
1.Simple mouse click to write program.
2.Automatic analysis on diameter, proportion of cavity, area and roundness of BGA.
3.Automatic BGA detection program has high repeatability of detection results for process control.
4.The test results will be displayed on the screen and can be output to excel for review.
CNC programming
1. Simply mouse click to write detection program.
2. Sample tablecan be positioned in X, Y direction; X-ray optical tube and detector can be positioned in Z direction.
3. Software set voltage and current.
4. Image settings: brightness, contrast, auto gain and exposure.
5. Users can set the pause time for program switching.
6. Anti-collision system can meet the maximum tilt and observation.
Feature Of SMT X Ray machine
● 100KV 5μm X-ray tube, image intensifier with 2 mega pixels CCD camera.
● Multi-function workstation with ±60° "Arc" motion and X-Y multi-axis movement.
● X-ray tube & detector automatic lifting and descending, with convenient target point positioning system.
● Multi-function DXI image processing system, programmable detection.
● Max. loading area 510mm*420mm , max. detection area 435*385mm,with 1200X System Magnification.
