Product Details:
|
| Condition: | New | Machine Type: | Welding Manipulator |
|---|---|---|---|
| Applicable Industries: | Home Use, Retail, Electronic Repair Centre | Showroom Location: | Egypt, United States, India, Algeria |
| Video Outgoing-inspection: | Not Available | Machinery Test Report: | Not Available |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 1 Year |
| Core Components: | PLC | Warranty: | 1 Year |
| Key Selling Points: | Easy To Operate | Voltage: | 220V |
| Current: | Dependable | Rated Capacity: | 2500W |
| Rated Duty Cycle: | 100% | Dimensions: | L450*W470*H670mm |
| Usage: | Soldering | Machine Type: | WDS-700 Cell Phone Repair Machine |
| Total Power: | 2500W Max | Power Supply: | 220V±10% |
| Locating Way: | V-shape Slot + Universal Jigs | PCB Size: | Max 140*160mm Min 5*5 Mm |
| Applicable Chip Size: | Max 80*80mm, Min 1*1mm | Temperature Control: | Nozzle Size Available |
| Temperature Interface: | 1 Pcs | Electrical Materials: | Driving Motor+smart Temp.controller+color Touch Screen |
| Precision: | ±1℃ | After Warranty Service: | Online Support |
| Local Service Location: | Egypt, United States, India, Algeria | After-sales Service Provided: | Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support |
| High Light: | Auto WDS 700 IC Repairing Machine,700 IC Repairing Machine 2500W,ir welding machine 2500W |
||
Specifications:
1.WDS-700 bga rework station
2.Optical alignment
3.Automatic machine
4.MCGS touch screen
5.CE,ISO passed
6.Small size
Auto BGA rework station WDS-700 optical alignment cell phone repair hot air heating machine
Our BGA Rework Station/ BGA reballing station are widely used to replace and repair the BGA chip in laptop, mobile phone, xbox360,ps3,etc.
The main user is repairing shops and factory to provide the after-sales service and rework.
How to separate BGA chip from motherboard?
How to replace a new BGA chip?
Repair steps:
1) Separate the BGA chip from mother board –we called desoldering
2) Clean Pad
3) Reballing or replace a new BGA chip directly
4) Alignment/Positioning – Depend on experience ,silk frame ,optical camera
5) replace a new BGA chip - we called Soldering
Parameter of WDS-700 cell phone repair machine
| Place of Origin |
Guangdong , China |
| Brand Name | Wisdomshow / WDS |
|
Moed Number |
WDS-700 hot air infrared smd rework station |
| Superior function | Soldering and desoldering BGA Chip/Mini IC |
More details Parameter of WDS-700 cell phone repair machine
|
Business type |
BGA rework station factory |
|
Power supply |
AC 220V±10% 50/60Hz |
|
Total power |
Max 2500W |
|
Heater power |
Upper temp.zone 1200W,Down temp.zone 1200W |
|
Electrical material |
Driving motor+PLC smart temp.controller+color touch screen |
|
Temperature controlling |
(high precision K-sensor)(Closed Loop),independent temp.controller,the precision can reach ±1℃ |
|
Locating way |
V shape slot,PCB support jigs can adjust |
|
PCB size |
Max 140×160mm Min 5×5 mm |
|
Applicable chips |
Max 80×80mm Min 1×1 mm |
|
Overall dimension |
L450×W470×H670mm |
|
Temperature Interface |
1 pcs |
|
Weight of machine |
30KG |
|
Color |
Blue+White |
Full Specification of WDS-700 cell phone repair machine
***Independent 2 heating zones temperature control system
1.The upper and lower heating zone,temperature precision control within ±1℃. which can heat up at the same time from the top of he component to the bottom of the PCB; 8 segment temperature control independently.repair ic machine
2.Hot air district heating for BGA and PCB at the same time,the upper or lower temperature zones could be used alone and combine freely the energy of up and lower heating element.phone cpu bga chip remove tool
3.Adopted high precision K-type thermocouple close-loop control and PID parameter self-setting system;
4 temperature curves can be displayed with instant curve analysis function and multi-group user data can be saved;temperature can be tested precisely through external measurement interface,curves can be analysed,set and correct on the touch screen at any time.repair ic machine
***Precision optical alignment system
Using high definition and adjustable CCD color optical alignment system,beam split,amplification,lessening,fine adjustment and auto focus with the function that automatic color aberration resolution and brightness adjustment,adjustable image contrast;equipped with 15 ” high definition LCD monitor. cell phone repair station
***Multi-functional and humanized operation system
1.Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many kinds of titanium alloy BGA tuyere can be rotated in 360 degree for easy installation and replacement.
2.X,Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm.
***Superior safety protection function
With alarm function, after the BGA welding the machine can alarm by itself.
In the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.Temperature parameter having password protection to prevent any modification.
***Higher automatic function
Newest WDS-700 is the updated system with 5 modes.It’s Remove,Mount,Weld,Manual and Semi-auto.The mode can be changed freely.It can be used under automatic,semi-auto & manual mode.repair ic machine
