WDS-650 Infrared BGA Rework Station Repair Motherboards Soldering Repairing

Description
Product Name: WDS-650 Bga Rework Station Function: Repair Motherboards
Power Supply: AC 220V+-10% 50/60Hz PCB Size: Max470*380mm Min10*10mm
Chip Size: Max70*70mm Min1*1mm PCB Thickness: 0.3-5mm
Mounting Precision: +-0.01mm Temperature Interface: 3pcs
High Light:

Soldering Repairing Infrared BGA Rework Station

,

Repair Motherboards Infrared BGA Rework Station

,

BGA infrared soldering station

Product Description
WDS-650 Infrared BGA Rework Station Repair Motherboards Soldering Repairing 0
Our BGA Rework Station/ BGA reballing station are widely used to replace and repair the BGA chip in laptop, mobile phone,xbox360,ps3,etc.
The main user is repairing shops and factory to provide the after-sales service and rework.
WDS-650 Infrared BGA Rework Station Repair Motherboards Soldering Repairing 1
Main Features
BGA Rework Station
Model:WDS-650
♦ 5 working modes
♦ 15’’ HD LCD monitor
♦ 7’’ HD touch screen
♦ CCD color optical alignment system
♦ Laser light for positioning
♦ Infrared preheat tubes + hot air heating areas
♦ HD camera comes in & out automatically by button
♦ Tenperature accuracy within ±1℃
♦ Mounting precision within ±0.01mm
♦ Repair success rate: 99% +
WDS-650 Infrared BGA Rework Station Repair Motherboards Soldering Repairing 2
Independent 3 heating zones temperature control system
1.The upper and lower hot air heating,which can heat up at the same time from the top of the component to the bottom of the PCB; bottom IR heating, temperature precision control within ±1℃.8 segment temperature control independently.
2.Hot air district heating for BGA and PCB at the same time,and large area IR heater preheating up for the bottom of PCB to avoid completely PCB deformation during reworking,the upper or lower temperature zones could be used alone and combine freely the energy of up and lower heating element.
3.Adopted high precision K-type thermocouple close-loop control and PID parameter self-setting system; 4 temperature curves can be displayed with instant curve analysis function and multi-group user data can be saved;temperature can be tested precisely through external measurement interface,curves can be analysed,set and correct on the touch screen at any time.
WDS-650 Infrared BGA Rework Station Repair Motherboards Soldering Repairing 3
Precision optical alignment system
Using high definition and adjustable CCD color optical alignment system,beam split,amplification ,lessening,fine adjustment and auto focus with the function that automatic color aberration resolution and brightness adjustment,adjustable image contrast;equipped with 15 ” high definition LCD monitor.
WDS-650 Infrared BGA Rework Station Repair Motherboards Soldering Repairing 4
Multi-functional and humanized operation system
1.Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many kinds of titanium alloy BGA tuyere can be rotated in 360 degree for easy installation and replacement.
2.X,Y and R angle adopted micrometer fine tuning,accuracy locating,precision can reach ±0.01mm.
WDS-650 Infrared BGA Rework Station Repair Motherboards Soldering Repairing 5
Superior safety protection function
With the alarm function, after the BGA welding, the machine can alarm by itself.In the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.Temperature parameter has password protection to prevent any modification.

How to separate BGA chip from motherboard?
How to replace a new BGA chip?

Repair steps:
1) Separate the BGA chip from motherboard –we called desoldering
2) Clean Pad
3) Reballing or replace a new BGA chip directly
4) Alignment/Positioning – Depend on experience ,silk frame ,optical camera
5) replace a new BGA chip - we called Soldering
Power supply
AC 220V±10％ 50/60Hz
Total power
Max 6400W
Heater power
Upper temp.zone 1200W,second temp.zone 1200W,IR temp.zone 4000W
Electrical material
Driving motor+PLC smart temp.controller+color touch screen
Temperature controlling
(high precision K-sensor)(Closed Loop),independent temp.controller,the precision can reach ±1℃
Locating way
V shape slot,PCB support jigs can adjust,laser light do fast centering and position
PCB size
Max 410×380mm Min10×10mm
Applicable chips
Max 70×70mm Min1×1mm
Overall dimension
L600×W640×H850mm
Temperature Interface
1 pcs
Weight of machine
60KG
Color
White&blue
Work mode
5 modes for choose,auto/manual work mode can be changed freely
